Technical Data
| Angle of rotation: | 90° |
| Torque: | < 1 Nm |
| Leakage: | < 1.5% of Kvs at 50 kPa |
| Max. working pressure: | 1.0 MPa (10 bar) |
| Max. differential pressure: | 50 kPa (0,5 bar) |
| Working temperature: | Min. 5 °C/Max. 110 °C (120 °C briefly) |
| Ambient temperature: | Min. 5 °C/Max. 60 °C |
| Thread standard: | G – male thread |
| Media 1: | Water – Glycol mixture max. 50% Ethanol mixture max. 30% |
| Material, valve body: | Brass EN 1982 CB753S |
| Material, internal cover: | PPS Composite |
| Material, external cover: | Aluminium |
| Material, slide/spindle: | Brass EN 12165 CW617N |
| Material, sealing: | EPDM |
| Spindle sealing: | Two O-rings |
